Laser welded pipe L=1.5m

Longitudinally laser welded pipes for use in overpressure, under-pressure and pressureless systems.

Product range

Diameter	Length	Thickness	Item ID	Edge
Ød, mm	L, mm	s, mm
500	1,490	0.88	AAAA000017	fb
550	1,490	1	AAAA000018	fb
600	1,490	1	AAAA000019	fb
630	1,490	1	AAAA000020	fb
650	1,490	1	AAAA000021	fb
700	1,490	1	AAAA000106	fb
750	1,490	1	AAAA000107	fb
800	1,490	1	AAAA000108	fb
850	1,490	1	AAAA000109	fb
900	1,490	1	AAAA000110	fb
950	1,490	1.25	AAAA000111	fb
1,000	1,490	1.25	AAAA000112	fb
500	1,490	0.88	AAAA000101	L.fl
550	1,490	1	AAAA000102	L.fl
600	1,490	1	AAAA000103	L.fl
630	1,490	1	AAAA000104	L.fl
650	1,490	1	AAAA000105	L.fl
700	1,490	1	AAAA000022	L.fl
750	1,490	1	AAAA000023	L.fl
800	1,490	1	AAAA000024	L.fl
850	1,490	1	AAAA000025	L.fl
900	1,490	1	AAAA000026	L.fl
950	1,490	1.25	AAAA000027	L.fl
1,000	1,490	1.25	AAAA000028	L.fl

Price	Diameter	Length	Thickness	Item ID	Edge
€	Ød, mm	L, mm	s, mm
€82.40	80	1,490	0.80	ABAA000001	fb
€102.80	100	1,490	0.80	ABAA000002	fb
€123.30	120	1,490	0.80	ABAA000003	fb
€134.50	125	1,490	0.80	ABAA000054	fb
€145.70	140	1,490	0.80	ABAA000004	fb
€145.70	150	1,490	0.80	ABAA000005	fb
€147.40	160	1,490	0.80	ABAA000006	fb
€165.70	180	1,490	0.80	ABAA000007	fb
€169.60	200	1,490	0.80	ABAA000008	fb
€212.10	225	1,490	0.80	ABAA000009	fb
€212.10	250	1,490	0.80	ABAA000010	fb
€254.30	275	1,490	0.80	ABAA000011	fb
€254.30	280	1,490	0.80	ABAA000055	fb
€254.30	300	1,490	0.80	ABAA000012	fb
€267.20	315	1,490	0.80	ABAA000013	fb
€297.00	350	1,490	0.80	ABAA000014	fb
€339.50	400	1,490	0.80	ABAA000015	fb
€381.70	450	1,490	0.80	ABAA000016	fb
€438.70	500	1,490	0.80	ABAA000017	fb
